BUILT FOR STRAIGHT BEAM BRIDGES • CONCRETE OR STEEL • UNLIMITED SPANS
Built for civil engineering firms, state DOTs, and private contractors.
Bridge Layouts By Tomorrow
Automated drafting for straight, constant-depth beam bridges. Submit your geometry. Receive text script views for use in AutoCAD or MicroStation, founder-overseen, by the end of the next business day.
TRADITIONAL DRAFTING
24 hrs
Average time for a drafter to produce general layout, deck, and elevation drawings by hand.
EXPRESS BRIDGE LAYOUTS
10 min
Automation runtime. Founder-overseen, delivered by end of next business day.
"10 min" is the automation runtime, not your total wait. Project review, founder oversight, and queue position make the full turnaround time "by end of next business day" — usually faster, occasionally up to one full business day during peak load.
You finalize dimensions. We deliver the heavy lift.
Is your bridge a fit?
In scope
- Straight-alignment beam/girder bridges
- Constant-depth superstructure (flat soffit)
- Multi-span, pier-supported
- Concrete or steel girders
- Unlimited spans (any length combination)
- Standard skew angles
Out of scope
- Curved or turning alignments
- Arch, cable-stayed, suspension, truss bridges
- Variable-depth or haunched girders
- Box girders with non-flat soffits
- Movable bridges
How It Works
01
Sign up & submit
Create an account, fill in the geometry for your view(s).
02
We generate your views
Dr. Harajli runs your inputs through our automation. (EBL does not perform engineering review or stamp deliverables — see Terms.)
03
Download & draft
Drop your three views — Layout.txt, Deck.txt, and Elevation.txt — into AutoCAD or MicroStation. Add dimensions and run engineer-of-record review.
Pricing
Single View
$75 / view
- —Choice of View 1, 2, or 3
- —Runs in AutoCAD & MicroStation
- —Delivered by end of next business day
- —1 revision included
- —TXT script delivery
Geometric drawings only. Client adds dimensions and obtains engineer-of-record approval. See Terms.
MOST POPULAR
Full Package
$225 / project
- —All three views (Layout, Deck, Elevation)
- —Delivered by end of next business day
- —2 revisions included
- —Founder-overseen quality process
- —Layer convention matching
Geometric drawings only. Client adds dimensions and obtains engineer-of-record approval. See Terms.
Volume Retainer
INQUIRE
Custom / month
- —5 base projects per month at discounted pricing
- —+20% surcharge for projects 6–10
- —Priority 2-hour rush turnaround on first 5
- —Direct line to the founder
- —Quarterly account review
Geometric drawings only. Client adds dimensions and obtains engineer-of-record approval. See Terms.
Dr. Ali A. Harajli, PhD
Founder & Principal
30+ years of professional bridge engineering in Colorado. Former Senior Manager at the CDOT Bridge Engineering Division. Designs and oversees EBL's automation quality standards. Note: EBL deliverables are not PE-stamped — see About for details.
Read the full profile →
